Hydraulic Bunker for Sale

Component Composition: Comprises the upper casing, intermediate bin, cooling net, vibrating screen, frame, observation window, dust bag, fan, and other parts.

Function: Specifically designed for cooling high - temperature particles post - granulation, reducing their temperature and humidity to simplify transportation and storage.

Cooling Effect: Granules fresh from the granulator can hit nearly 70°C, being fragile and generating water vapor easily. After cooling, their temperature nears room temperature, allowing direct packaging. It’s a key element in large - scale production lines, helping particles progress to the packaging stage.

Material Advantage: Unlike older models, it’s constructed from thick galvanized sheets, boasting high density, great anti - deformation and anti - corrosion capabilities, and a prolonged service life.

Contact Now E-Mail Telephone WhatsApp

Product Details

Hydraulic Bunker Product Introduction

Hydraulic Bunker Features

Modular Structure Design

The Hydraulic Bunker features a split modular structure, which streamlines transportation and installation, showcasing advanced engineering know - how. Laser - cutting technology is employed for blanking and punching each module, guaranteeing precise manufacturing and a seamless, efficient setup.

Superior Frame Construction

The main frame of the Hydraulic Bunker is formed by bending galvanized sheets. Compared with traditional iron - plate welding, this method significantly increases the structural strength. The galvanized sheet material also has excellent corrosion - resistance, enhancing the equipment's durability and extending its service life.

Comprehensive System Composition

The Hydraulic Bunker is a well - designed system, mainly consisting of a gantry, a sliding main beam, movable and fixed material - dialing wings, hydraulic cylinders, a hydraulic station, a discharging screw conveyor, and the bunker body. Its sealed material - storage design solves the problems of open - air material storage. It reduces environmental pollution and operational interference caused by dust, and decreases the need for forklifts and manual material handling, thus saving costs. Additionally, an explosion - proof vent is installed on the bunker roof, which effectively reduces the risk of dust explosions and ensures operational safety.

Hydraulic Bunker Product Parameters
Volume Range （m³）	Specification	Overall Dimensions (m)	Total Volume (m³）	Power （kw）	Output	Customer - supplied Embedded Materials
<100	One - station Two - cylinder	2.5x6x3.58	53	7.5	1-3T	200*200Hsteel	Iron Plate Dimensions:	Ground Screw Bolt Specification
	One - station Two - cylinder	2.5x6x2.58	38	7.5		42m	3m	Φ20*220
	One - station Two - cylinder	2.5x6x4.74	71	7.5			2*20mm thick
100~200	Two - stations Four - cylinder	5x8x2.58	103	11*2	4-10T
	Two - stations Four - cylinder	5x8x3.58	143	11*2		70m	3m	Φ20*220
	Two - stations Four - cylinder	5x8x4.74	189	11*2			2*20mm thick
200~300	Two - stations Four - cylinder	5x8x5.74	229	11*2
Remarks: The above specifications are the parameters of the hydraulic warehouse, excluding the customer's own steel frame and foundation embedded parts, excluding the dragon
